Extend your Wi-Fi coverage to every corner of your home, eliminating dead zones for uninterrupted connectivity, powered by Cudy Mesh technology.

Quick Specs
Eliminate Wi-Fi dead zones and extend coverage by up to 130 meters.
Achieve speeds of up to 300 Mbps on the 2.4 GHz band for smooth browsing and streaming.
Seamlessly integrate into your existing Cudy Mesh network for a unified Wi-Fi experience.
Connect up to 30 devices with stable performance, ideal for modern households.
Simple setup with WPS button and intuitive signal strength indicators.

Unlock seamless connectivity throughout your South African home

Engineered for robust performance and broad reach

Effortless integration with Cudy Mesh technology

Reliable connectivity for multiple devices

Simple operation and dependable performance


FEATURES:
Boost your Wi-Fi signal: Extend your network’s reach by up to 130 meters, ensuring strong and stable internet in every room and eliminating Wi-Fi dead zones with this effective Wi-Fi range extender.
Achieve faster speeds: Benefit from 300 Mbps speeds on the 2.4 GHz band, perfect for smooth web browsing, streaming your favourite shows, and everyday online activities with this powerful Cudy range extender.
Seamless Cudy Mesh integration: Easily add the N300 as a satellite to your Cudy Mesh network for a unified and intelligent Wi-Fi experience throughout your home.
Connect more devices: Support for up to 30 connected clients ensures reliable performance for smartphones, laptops, smart home devices, and more.
Effortless setup and management: Utilize the simple WPS button for quick pairing and rely on intuitive signal strength LEDs to find the optimal placement for peak performance.
Secure your connection: Employ robust WPA/WPA2/WPA3 security protocols to protect your network from unauthorized access and ensure data privacy.
Versatile operation modes: Function as a range extender, access point, or client device to best suit your network configuration needs.

SPECIFICATIONS:
Memory/Storage
Flash/ROM: 8 MB (64 Mbit ) NOR
DDR/RAM: 64 MB (512 Mbit ) DDR2
Wireless
2.4 GHz Wi-Fi Speed: 300 Mbps
2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 2× Fixed
FEM or PA /LNA: 2.4 GHz: 2× Internal
Range Performance: Max: 130 m (427 ft )*
Wall Performance: One wooden walls with thickness < 10 cm (4”) | One concrete wall with thickness < 10 cm (4”)
*Tested in open-space environments with minimal interference. Actual Wi-Fi range may var y depending on layout and wall materials.
*Refer to the Wall Performance specifications for placement suggestions.
Interfaces
10/100 Mbps RJ45 Ports: 1
Ethernet Notes: 1× LAN Port
LED: Signal Strength | WPS | Power
Physical Buttons: WPS Button | Reset Button
Power Input: AC Plug
Wireless
Wi-Fi Standards: Wi-Fi 4
Max Wi-Fi Modulation: 64-QAM
Max Capacity: 64
Recommended Client Upper Limit: 30
Max Wi-Fi Channel Width: 40 MHz
Wi-Fi Security: WPA/WPA2/WPA3
WPS: True
General
Operation Modes: Access Point | Range Extender | Client
Mesh: Cudy Mesh Satellite
Mesh Backhaul: Wireless Backhaul | Wired Backhaul
Multi-Band Backhaul: True
System
LED Control: True
Local Control Method: Config Web Page | App Control
Remote Control Method: App Control
Firmware Upgrade: Local Update | App (Over the Air) | Online Update
Reliability: Timed Reboot | Backup and Restore
Dashboard
Panel: Connected Devices | Host Network Status | Wi-Fi Status | LAN Status | System Version
Power
Power Methods: AC
AC: 100V ~ 240V
Environment
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 95% non-condensing
Certifications: FCC, CE
Colour: White
Product Dimensions: 8 x 6 x 3.8 cm

WHAT’S IN THE BOX:
Cudy N300 Mesh Wi-Fi Range Extender – White x1
Installation Guide x1

Why Cudy?
Cudy provides reliable and accessible networking solutions designed for the modern home and office. With a focus on user-friendly technology and robust performance, Cudy empowers South African users to build stronger, more stable connections. Choose Cudy for dependable Wi-Fi that keeps pace with your digital life. This Cudy range extender is a smart choice for any home.
